Product Set
Outdoor Unit
Indoor Unit
Controller
Features
Even Airflow
Enjoy an even temperature throughout the room. 3D Airflow directs air horizontally as well as vertically, for consistently spread heating and cooling.
Turbo Cooling
With the Turbo function the motor and fan work at a higher frequency, so you can enjoy a cool room within a much shorter time.
Whisper Quiet
Enjoy consistent temperature as well as peace and quiet. Our wall mounted split system air conditioning / heat pump are very quiet and can operate from as low as 21 decibels.
Easy Installation
Designed for easy installation, Haier Quartz air conditioners / heat pump come with simple positioning Specifications. The control board and motor are also easily accessible for fast maintenance.
Technologies
UV Protect
UV Protect helps to deliver clean air to your room using Health mode, with built-in LED UV lights that kill airborne pathogens, delivering clean air to your room.*
*Independent testing has found 91.47% elimination of the H3N2 virus in a 30m2 closed room and 92.78% of Staphylococcus aureus bacteria in a 10m3 closed room, for two hours on Health mode at the highest fan speed.
Coanda Plus Airflow
Coanda Plus airflow technology sends warm or cool air further, for maximum comfort throughout the room.
Self-Clean
The Self-clean function freezes the indoor and outdoor coil with moisture in the air and flushes away dirt through melting, helping to ensure healthy airflow from your air conditioner.
WiFi
We believe in integrating smart technology into the heart of every home. The SmartHQ™ app puts control in your hands and means you can control your air-conditioning / heat pump from anywhere at anytime. Our products are also compatible with Google Home and Amazon Alexa.
Specifications
Quartz Hi Wall, 2.5kW
AS25QCEHRA-SET
Capacity
Cooling capacity (kW): 2.5kW
Heating capacity (kW): 3.2kW
Consumption
COP: 4.57 / 4.52
EER: 4.81 / 4.73
HSPF-RES (Hot/Average/Cold): 4.913 / 4.543 / 4.042
Star-Cool (Hot/Average/Cold): 10.0 / 7.0 / 7.5
Star-Heat (Hot/Average/Cold): 3.0 / 3.0 / 2.5
TCSPF-RES (Hot/Average/Cold): 12.196 / 8.799 / 9.388
Product dimensions
Indoor unit depth : 217mm
Indoor unit height: 307mm
Indoor unit width: 875mm
Outdoor unit depth : 275mm
Outdoor unit height : 553mm
Outdoor unit width: 800mm
Warranty
Parts and labour: 5 years
Accessories (included)
Central controller: Optional
IR Controller:
SmartHQ WiFi control:
Standard controller: YR-HJ
Capacity
Cooling capacity (kW): 2.5kW
Heating capacity (kW): 3.2kW
Consumption
COP: 4.57 / 4.52
EER: 4.81 / 4.73
HSPF-RES (Hot/Average/Cold): 4.913 / 4.543 / 4.042
Star-Cool (Hot/Average/Cold): 10.0 / 7.0 / 7.5
Star-Heat (Hot/Average/Cold): 3.0 / 3.0 / 2.5
TCSPF-RES (Hot/Average/Cold): 12.196 / 8.799 / 9.388
Features
24 Hour timer:
Anti-bacterial silver ion coating:
Auto restart:
Auto swing-up and down:
Blue fin coils:
Built-in Wi-Fi smart control:
Compressor type: Inverter twin rotary
Concealed LED display:
DRED (Demand Response) ready: Optional HPRT-DRA001
Dry mode:
Electronic expansion device:
Google Home:
Heat pump:
Infrared remote control:
Intelligent air:
Internal and external heat exchanger self-cleaning:
MEPS approved:
Motor type: DC motor
Power mode:
Refrigerant factory charge: 1kg
Self diagnostics:
Sleep mode:
UV Protect:
Voice control via Google Home or Amazon Alexa:
Wi-Fi controller compatible:
Installation
Indoor unit model: AS25QCEHRA
Indoor unit weight: 10kg
Outdoor unit model: 1U25MAEFRA
Outdoor unit weight: 30kg
Pipe length maximum: 15m
Pipe size gas: 9.52mm
Pipe size liquid: 6.35mm
Performance
Airflow: 195L/S
DC inverter:
Indoor sound pressure SPL: 40 / 36 / 32 / 21dBA
Outdoor sound power SWL: 61dBA
Outdoor sound pressure SPL: 51dBA
R32 Refrigerant:
Self cleaning evaporator:
Working temperature cooling: -10°C to +46°C
Working temperature heating: -15°C to +24°C
Power requirements
Supply frequency: 50Hz
Supply voltage: 220-240V
Product dimensions
Indoor unit depth : 217mm
Indoor unit height: 307mm
Indoor unit width: 875mm
Outdoor unit depth : 275mm
Outdoor unit height : 553mm
Outdoor unit width: 800mm
Warranty
Parts and labour: 5 years
Download resources
General
-
Service & Warranty Booklet
Quartz (Heating and Cooling), GeneralFiles-HaierHVACNZ
-
User Guide
Quartz (Heating and Cooling), GeneralFiles-HaierHVACNZ
-
Product Brochure
Quartz (Heating and Cooling), GeneralFiles-HaierHVACNZ
Installation
-
Installation Guide
Quartz (Heating and Cooling), InstallationManuals-HaierHVACNZ
Quartz Hi Wall, 3.5kW
AS35QCEHRA-SET
Capacity
Cooling capacity (kW): 3.5kW
Heating capacity (kW): 3.7kW
Consumption
COP: 4.30 / 4.26
EER: 4.22 / 4.17
HSPF-RES (Hot/Average/Cold): 5.004 / 4.542 / 3.968
Star-Cool (Hot/Average/Cold): 8.5 / 6.0 / 7.0
Star-Heat (Hot/Average/Cold): 3.5 / 3.0 / 2.0
TCSPF-RES (Hot/Average/Cold): 10.253 / 7.910 / 8.612
Product dimensions
Indoor unit depth : 217mm
Indoor unit height: 307mm
Indoor unit width: 875mm
Outdoor unit depth : 275mm
Outdoor unit height : 553mm
Outdoor unit width: 800mm
Warranty
Parts and labour: 5 years
Accessories (included)
Central controller: Optional
IR Controller:
SmartHQ WiFi control:
Standard controller: YR-HJ
Capacity
Cooling capacity (kW): 3.5kW
Heating capacity (kW): 3.7kW
Consumption
COP: 4.30 / 4.26
EER: 4.22 / 4.17
HSPF-RES (Hot/Average/Cold): 5.004 / 4.542 / 3.968
Star-Cool (Hot/Average/Cold): 8.5 / 6.0 / 7.0
Star-Heat (Hot/Average/Cold): 3.5 / 3.0 / 2.0
TCSPF-RES (Hot/Average/Cold): 10.253 / 7.910 / 8.612
Features
24 Hour timer:
Anti-bacterial silver ion coating:
Auto restart:
Auto swing-up and down:
Blue fin coils:
Built-in Wi-Fi smart control:
Compressor type: Inverter twin rotary
Concealed LED display:
DRED (Demand Response) ready: Optional HPRT-DRA001
Dry mode:
Electronic expansion device:
Google Home:
Heat pump:
Infrared remote control:
Intelligent air:
Internal and external heat exchanger self-cleaning:
MEPS approved:
Motor type: DC motor
Power mode:
Refrigerant factory charge: 1.02kg
Self diagnostics:
Sleep mode:
UV Protect:
Voice control via Google Home or Amazon Alexa:
Wi-Fi controller compatible:
Installation
Indoor unit model: AS35QCEHRA
Indoor unit weight: 10kg
Outdoor unit model: 1U35MAEFRA
Outdoor unit weight: 30kg
Pipe length maximum: 15m
Pipe size gas: 9.52mm
Pipe size liquid: 6.35mm
Performance
Airflow: 210L/S
DC inverter:
Indoor sound pressure SPL: 40 / 36 / 32 / 22dBA
Outdoor sound power SWL: 63dBA
Outdoor sound pressure SPL: 52dBA
R32 Refrigerant:
Self cleaning evaporator:
Working temperature cooling: -10°C to 46°C
Working temperature heating: -15°C to 24°C
Power requirements
Supply frequency: 50Hz
Supply voltage: 220-240V
Product dimensions
Indoor unit depth : 217mm
Indoor unit height: 307mm
Indoor unit width: 875mm
Outdoor unit depth : 275mm
Outdoor unit height : 553mm
Outdoor unit width: 800mm
Warranty
Parts and labour: 5 years
Download resources
General
-
Service & Warranty Booklet
Quartz (Heating and Cooling), GeneralFiles-HaierHVACNZ
-
User Guide
Quartz (Heating and Cooling), GeneralFiles-HaierHVACNZ
-
Product Brochure
Quartz (Heating and Cooling), GeneralFiles-HaierHVACNZ
Installation
-
Installation Guide
Quartz (Heating and Cooling), InstallationManuals-HaierHVACNZ
Quartz Hi Wall, 5kW
AS50QDEHRA-SET
Capacity
Cooling capacity (kW): 5kW
Heating capacity (kW): 6kW
Consumption
COP: 4.05 / 4.02
EER: 4.03 / 4.00
HSPF-RES (Hot/Average/Cold): 5.067 / 4.302 / 3.670
Star-Cool (Hot/Average/Cold): 6.0 / 5.0 / 5.5
Star-Heat (Hot/Average/Cold): 3.5 / 2.5 / 2.0
TCSPF-RES (Hot/Average/Cold): 7.934 / 6.834 / 7.373
Product dimensions
Indoor unit depth : 220mm
Indoor unit height: 320mm
Indoor unit width: 970mm
Outdoor unit depth : 340mm
Outdoor unit height : 705mm
Outdoor unit width: 890mm
Warranty
Parts and labour: 5 years
Accessories (included)
Central controller: Optional
IR Controller:
SmartHQ WiFi control:
Standard controller: YR-HJ
Capacity
Cooling capacity (kW): 5kW
Heating capacity (kW): 6kW
Consumption
COP: 4.05 / 4.02
EER: 4.03 / 4.00
HSPF-RES (Hot/Average/Cold): 5.067 / 4.302 / 3.670
Star-Cool (Hot/Average/Cold): 6.0 / 5.0 / 5.5
Star-Heat (Hot/Average/Cold): 3.5 / 2.5 / 2.0
TCSPF-RES (Hot/Average/Cold): 7.934 / 6.834 / 7.373
Features
24 Hour timer:
Anti-bacterial silver ion coating:
Auto restart:
Auto swing-up and down:
Blue fin coils:
Built-in Wi-Fi smart control:
Compressor type: Inverter twin rotary
Concealed LED display:
DRED (Demand Response) ready: Optional HPRT-DRA001
Dry mode:
Electronic expansion device:
Google Home:
Heat pump:
Infrared remote control:
Intelligent air:
Internal and external heat exchanger self-cleaning:
MEPS approved:
Motor type: DC motor
Power mode:
Refrigerant factory charge: 1.02kg
Self diagnostics:
Sleep mode:
UV Protect:
Voice control via Google Home or Amazon Alexa:
Wi-Fi controller compatible:
Installation
Indoor unit model: AS50QDEHRA
Indoor unit weight: 11.6kg
Outdoor unit model: 1U50WAEFRA
Outdoor unit weight: 43.2kg
Pipe length maximum: 25m
Pipe size gas: 12.7mm
Pipe size liquid: 6.35mm
Performance
Airflow: 265L/S
DC inverter:
Indoor sound pressure SPL: 47 / 43 / 37 / 33dBA
Outdoor sound power SWL: 66dBA
Outdoor sound pressure SPL: 53dBA
R32 Refrigerant:
Self cleaning evaporator:
Working temperature cooling: -10°C to +46°C
Working temperature heating: -15°C to +24°C
Power requirements
Supply frequency: 50Hz
Supply voltage: 220-240V
Product dimensions
Indoor unit depth : 220mm
Indoor unit height: 320mm
Indoor unit width: 970mm
Outdoor unit depth : 340mm
Outdoor unit height : 705mm
Outdoor unit width: 890mm
Warranty
Parts and labour: 5 years
Download resources
General
-
Service & Warranty Booklet
Quartz (Heating and Cooling), GeneralFiles-HaierHVACNZ
-
User Guide
Quartz (Heating and Cooling), GeneralFiles-HaierHVACNZ
-
Product Brochure
Quartz (Heating and Cooling), GeneralFiles-HaierHVACNZ
Installation
-
Installation Guide
Quartz (Heating and Cooling), InstallationManuals-HaierHVACNZ
Quartz Hi Wall, 7kW
AS71QEEHRA-SET
Capacity
Cooling capacity (kW): 7.1kW
Heating capacity (kW): 8kW
Consumption
COP: 3.51 / 3.49
EER: 3.51 / 3.49
HSPF-RES (Hot/Average/Cold): 4.935 / 4.242 / 3.635
Star-Cool (Hot/Average/Cold): 5.5 / 4.5 / 5.0
Star-Heat (Hot/Average/Cold): 3.0 / 2.5 / 2.0
TCSPF-RES (Hot/Average/Cold): 7.036 / 6.138 / 6.646
Product dimensions
Indoor unit depth : 240mm
Indoor unit height: 345mm
Indoor unit width: 1106mm
Outdoor unit depth : 340mm
Outdoor unit height : 705mm
Outdoor unit width: 890mm
Warranty
Parts and labour: 5 years
Accessories (included)
Central controller: Optional
IR Controller:
SmartHQ WiFi control:
Standard controller: YR-HJ
Capacity
Cooling capacity (kW): 7.1kW
Heating capacity (kW): 8kW
Consumption
COP: 3.51 / 3.49
EER: 3.51 / 3.49
HSPF-RES (Hot/Average/Cold): 4.935 / 4.242 / 3.635
Star-Cool (Hot/Average/Cold): 5.5 / 4.5 / 5.0
Star-Heat (Hot/Average/Cold): 3.0 / 2.5 / 2.0
TCSPF-RES (Hot/Average/Cold): 7.036 / 6.138 / 6.646
Features
24 Hour timer:
Anti-bacterial silver ion coating:
Auto restart:
Auto swing-up and down:
Blue fin coils:
Built-in Wi-Fi smart control:
Compressor type: Inverter twin rotary
Concealed LED display:
DRED (Demand Response) ready: Optional HPRT-DRA001
Dry mode:
Electronic expansion device:
Google Home:
Heat pump:
Infrared remote control:
Intelligent air:
Internal and external heat exchanger self-cleaning:
MEPS approved:
Motor type: DC motor
Power mode:
Refrigerant factory charge: 1.42kg
Self diagnostics:
Sleep mode:
UV Protect:
Voice control via Google Home or Amazon Alexa:
Wi-Fi controller compatible:
Installation
Indoor unit model: AS71QEEHRA
Indoor unit weight: 15.5kg
Outdoor unit model: 1U71WAEFRA
Outdoor unit weight: 44kg
Pipe length maximum: 25m
Pipe size gas: 12.70mm
Pipe size liquid: 6.35mm
Performance
Airflow: 310L/S
DC inverter:
Indoor sound pressure SPL: 48 / 44 / 38 / 33dBA
Outdoor sound power SWL: 68dBA
Outdoor sound pressure SPL: 54dBA
R32 Refrigerant:
Self cleaning evaporator:
Working temperature cooling: -10°C to +46°C
Working temperature heating: -15°C to +24°C
Power requirements
Supply frequency: 50Hz
Supply voltage: 220-240V
Product dimensions
Indoor unit depth : 240mm
Indoor unit height: 345mm
Indoor unit width: 1106mm
Outdoor unit depth : 340mm
Outdoor unit height : 705mm
Outdoor unit width: 890mm
Warranty
Parts and labour: 5 years
Download resources
General
-
Service & Warranty Booklet
Quartz (Heating and Cooling), GeneralFiles-HaierHVACNZ
-
User Guide
Quartz (Heating and Cooling), GeneralFiles-HaierHVACNZ
-
Product Brochure
Quartz (Heating and Cooling), GeneralFiles-HaierHVACNZ
Installation
-
Installation Guide
Quartz (Heating and Cooling), InstallationManuals-HaierHVACNZ
Quartz Hi Wall, 9kW
AS90QFDHRA-SET
Capacity
Cooling capacity (kW): 9kW
Heating capacity (kW): 9.5kW
Consumption
COP: 3.57 / 3.54
EER: 3.40 / 3.37
HSPF-RES (Hot/Average/Cold): 4.481 / 3.908 / 3.392
Star-Cool (Hot/Average/Cold): 4.5 / 3.5 / 4.0
Star-Heat (Hot/Average/Cold): 2.5 / 2.0 / 1.5
TCSPF-RES (Hot/Average/Cold): 6.078 / 5.394 / 5.746
Product dimensions
Indoor unit depth : 275mm
Indoor unit height: 365mm
Indoor unit width: 1316mm
Outdoor unit depth : 370mm
Outdoor unit height : 815mm
Outdoor unit width: 950mm
Warranty
Parts and labour: 5 years
Accessories (included)
Central controller: Optional
IR Controller:
SmartHQ WiFi control:
Standard controller: YR-HJ
Capacity
Cooling capacity (kW): 9kW
Heating capacity (kW): 9.5kW
Consumption
COP: 3.57 / 3.54
EER: 3.40 / 3.37
HSPF-RES (Hot/Average/Cold): 4.481 / 3.908 / 3.392
Star-Cool (Hot/Average/Cold): 4.5 / 3.5 / 4.0
Star-Heat (Hot/Average/Cold): 2.5 / 2.0 / 1.5
TCSPF-RES (Hot/Average/Cold): 6.078 / 5.394 / 5.746
Features
24 Hour timer:
Anti-bacterial silver ion coating:
Auto restart:
Auto swing-up and down:
Blue fin coils:
Built-in Wi-Fi smart control:
Compressor type: Inverter twin rotary
Concealed LED display:
DRED (Demand Response) ready: Optional HPRT-DRA001
Dry mode:
Electronic expansion device:
Google Home:
Heat pump:
Infrared remote control:
Intelligent air:
Internal and external heat exchanger self-cleaning:
MEPS approved:
Motor type: DC motor
Power mode:
Refrigerant factory charge: 1.55kg
Self diagnostics:
Sleep mode:
UV Protect:
Voice control via Google Home or Amazon Alexa:
Wi-Fi controller compatible:
Installation
Indoor unit model: AS90QFDHRA
Indoor unit weight: 21.5kg
Outdoor unit model: 1U90QADFRA
Outdoor unit weight: 51kg
Pipe length maximum: 25m
Pipe size gas: 15.88mm
Pipe size liquid: 6.35mm
Performance
Airflow: 320L/S
DC inverter:
Indoor sound pressure SPL: 48 / 42 / 36 / 30dBA
Outdoor sound power SWL: 69dBA
Outdoor sound pressure SPL: 56dBA
R32 Refrigerant:
Self cleaning evaporator:
Working temperature cooling: -10°C to +46°C
Working temperature heating: -15°C to +24°C
Power requirements
Supply frequency: 50Hz
Supply voltage: 220-240V
Product dimensions
Indoor unit depth : 275mm
Indoor unit height: 365mm
Indoor unit width: 1316mm
Outdoor unit depth : 370mm
Outdoor unit height : 815mm
Outdoor unit width: 950mm
Warranty
Parts and labour: 5 years
Download resources
General
-
Service & Warranty Booklet
Quartz (Heating and Cooling), GeneralFiles-HaierHVACNZ
-
User Guide
Quartz (Heating and Cooling), GeneralFiles-HaierHVACNZ
-
Product Brochure
Quartz (Heating and Cooling), GeneralFiles-HaierHVACNZ
Installation
-
Installation Guide
Quartz (Heating and Cooling), InstallationManuals-HaierHVACNZ
